The Blastrac BDC-1340LPP is the top of the range dust collector for large concrete floor grinders and scarifiers and medium size shot blasters. As well as featuring a powerful 3 phase 4KW motor the BDC-1340LPP has the long pack bagging system with pulse cleaning. Pulse cleaning provides automatic cleaning of the onboard filters to allow for uninterruptable operation.
The BDC-1340LPP is compatible with a range of accessories to make your specific application more accessible. It features a more powerful 4kw motor for increased performance.
If you need anymore information on our dust collection and suppression systems including the new HEPA compliant systems please contact us today.
Feature |
Description |
Dimensions W/L/H |
600 x 1.200 x 1.600 mm |
Weight |
200 kg |
Motor Power |
4kW / 400 V single phase / 50Hz / 16A
4kW / 440 V single phase / 60Hz / 16A |
Dust Extraction Motors |
3 independent motors |
Filter |
M-class star filter |
Cleaning |
Automatic pulse cleaning system |
Bag Capacity |
25kg |
Dust Hose Inlet |
Ø 51mm / Ø 76mm |
Airflow |
7500 l/min |
Suitable Machines |
Large grinders and scarifiers, medium sized shot blasters |
Optional Dustbin |
100 Litres |
|
Options/Accessories
Feature |
Description |
10m Suction Hose Ø76 |
005014 |
20m Suction Hose Ø51 |
004583 |
M-Class star filter |
CF40000492 |
M-Class star filter PTFE |
CF32400327 |
M-Class star filter PTFE-anti-static |
CF32400329 |
Mobile Nozzle 400mm Width |
CF722029 |
Mobile Nozzle 500mm Width |
CF722147 |
Aluminium Hand Grip 50mm |
CF722025 |
Chrome Hand Grip 50mm |
CF722122 |
More tools |
on request |
4 pack lon pack sleeve (20mtr) |
BLS-1058 |
|
